JYAS-1000P-210
Can use in scribing the 156*156-210*210 mm² size solar cells. Scribing speed can reach 1000 mm/s.
Laser device: 1064nm Fiber Laser
Beam quality:1.3 ㎡
Table Movement distance: 300mm*300mm
Maximum scribing speed : N-Type 1200mm/s，P-Type:800-1000mm/s
Maximum speed: 1200mm/s
Scribing precision: ≤±0.05mm
Automatic positioning precision: ≤±0.05mm
Cooling system:Air-cooled
The line width: ≤0.03mm
Scribing structure: Single Stations
Scribing table:Vitreous table
Tray number: 2
Cell/wafer size:156×156-210×210 whole cells, non-standard cells, rice-grain cells, corner-missing cells
Compressed air: 0.5-0.8MPa
Input voltage: 220VAC/50HZ
Power consumption: 1KW
Machine dimension: 1100mm*780mm*1450mm
Machine weight: 350KG
