Ju Yang Laser Equipment
JYAH-1500P-210
Compatible with the scribing of 156156-210210mm² battery cells, it can break in half automatically.
Laser device : 1064nm Fiber Laser
Beam Quality : 1.3㎡
Table range : 600mm*400mm
Maxmum Scribing Speed : N-Type:1200mm/s,P-Type:800-1000mm/s
Maxmum Speed : 1200mm/s
Scribing accuracy : ≤±0.05mm
Positional accuracy : ≤±0.05mm
Scribing width : ≤0.03mm
Scribing struture : Double station scribing
Scribing table : Glass table
Tray quantity : 2
Cell/silicon size : 156×156-210×210mm full wafer, non-standard cells, rice-grain cells, corner-missing cells
Ceasma : Mechanical automatic split half piece
Air compression : 0.5-0.8MPa
Input voltage : 220VAC/50HZ
Machine power : 1.5KW
Machine size : 1200mm*850mm*1750mm
Machine Weight : 450KG
