Laser device : 1064nm Fiber Laser

Beam quality :1.3㎡

Table Movement distance : 600mm*400mm

Maximum scribing speed : N--Type:1200mm/s,P-Type:800-1000mm/s

Maximum speed : 1200mm/s Scribing depth : 0.05-0.07mm

Scribing precision : ≤±0.05mm

Automatic positioning precision : ≤±0.05mm

Cooling system : Air-cooled

The line width : ≤0.03mm

Scribing structure : Double Stations

Scribing table : Vitreous table

Tray number : 2

Cell size : 156×156-210×210mm full wafer, non-standard cells, rice-grain cells, corner-missing cells

Input voltage : 0.6-0.8MPa

Power consumption : 1KW

Machine dimension : 1200mm*850mm*1750mm

Machine weight : 450KG
